Ampeg PF-500 User Manual

PF-350 / PF-500 Bass Guitar Amplifier
PF-350 / PF-500 Bass Guitar Amplifier PF-350 / PF-500 Bass Guitar Amplifier
13
PF-500 Front Panel continued
thresh
input
-15dB
ultra lo
mute ultra hi
gaincompression bass midrange frequency treble volumefx mix
peak
mute
31 2 4 5
audio
in
phones
PF 500
0 100 100 100 100 100 10 0 10
fault
13 14 15 1716 18121110987654321
18. PHONES:Usethis1/8"TRSstereo
output to connect your headphones.
The output here is a mix of the line-level
signals reaching the amplifier, and any
incoming audio from the audio in
jack[17].
If you just want to listen and practice
through headphones, disconnect the
speaker-leveloutputs[23]fromthe
speaker cabinet. There is no harm in
playing the PF-500 without speakers.
Before putting on headphones, make
surethevolumecontrol[15]isturned
down, and (if connected) any external
audio source has its level turned down.
This will reduce the chance of hearing
damage due to loud volumes.

Ampeg PF-500 Specifications

General

Preamp	Solid State
Power Amp	Class D
Tone Controls	Bass, Mid, Treble
Mid Tone Control	5-position
Ultra Hi/Lo	Yes
Compressor	Yes
Effects Loop	Yes
Weight	11 lbs / 5 kg
Type	Bass Amplifier Head
Solid State or Tube	Solid State
Number of Channels	1
EQ	3-band
Footswitch I/O	No
Power Output	500W @ 4 ohms
Direct Out	Balanced XLR
Inputs	1 x 1/4"
Outputs	1 x XLR
Dimensions	14" x 11"
