Ampeg PF-500 User Manual

PF-350 / PF-500 Bass Guitar Amplifier
Flip-Top Instructions:
So you’ve made it this far and you are
now ready to flip your lid...or at least the
amp. We will instruct you on how to do
the latter, as we are not in the business
of lid-flipping!
It is accomplished in five simple steps:
Step 1: loosen the latches on each side
of the cabinet. There are two latches on
each side, four total.
Step 2: using the handle, lift the top of
the cabinet (amplifier is attached
underneath) and rotate it 180˚
clockwise (as indicated in the middle
drawing below).
Step 3: set the cabinet top handle-side
down on the top of the cabinet. The
amplifier should now be on the top, right-
side up, with the front of the amp and
the front of the cabinet facing the same
direction.
Step 4: line up and lock all four latches.
Step 5: rock out like there is no
tomorrow!
www.ampeg.com
©2011 LOUD Technologies Inc.
16220 Wood-Red Road NE • Woodinville, WA 98072
Part No. SW0855 Rev. E 01/11

Ampeg PF-500 Specifications

General

Preamp	Solid State
Power Amp	Class D
Tone Controls	Bass, Mid, Treble
Mid Tone Control	5-position
Ultra Hi/Lo	Yes
Compressor	Yes
Effects Loop	Yes
Weight	11 lbs / 5 kg
Type	Bass Amplifier Head
Solid State or Tube	Solid State
Number of Channels	1
EQ	3-band
Footswitch I/O	No
Power Output	500W @ 4 ohms
Direct Out	Balanced XLR
Inputs	1 x 1/4"
Outputs	1 x XLR
Dimensions	14" x 11"
