SOLEADO – INSTALLATION MANUAL
WORKING CONDITION
Ambient Temperature: -30˚C to 30˚C
Power Source: GPO Plug
Rated Voltage: 220-240V
Rated Frequency: 50Hz/60Hz
Relative Humidity: less than 95%
INSTALLATION CONDITIONS
1 Supply voltage fluctuation range should be within ±10%. If this range is not met, it must be
revised before installation.
2 If there is a serious security risk in the users’ electricity environment the installation should be
refused, until the elimination of the security risks is carried out.
3 Electrical lines must be equipped with earth leakage protection devices and master switch.
INSTALLATION CONDITIONS
MODEL NO. POWER (W)
RATED
CURRENT (A)
VOLTAGE (V) CABLE LENGTH (mm)
108100 2400 10 220-240 2000
108101 2400 10 220-240 2000
