AmpliVox S1234 - S1234 Passive Speaker Back Panel; SS1234;SW1234 Back Panel Controls; SW1234 Wireless UHF Receiver

4
 XLR / 1/4” COMBO
RCA Input Jacks
S1234 BACK PANEL
 DC ADAPTER CONNECTOR
 POWER SWITCH
 CHANNEL DISPLAY
 MINI JACK INPUT: (3.5mm)
 MICROPHONE VOLUME
CONTROL
 MINI JACK OUTPUT (3.5mm)
 MAIN VOLUME CONTROL
 RCA OUTPUT JACKS
SW1234 WIRELESS UHF RECEIVER
SS1234 / SW1234 BACK
The S1234 is a passive speaker. It has no built-in amplifier. It is designed to be used with the SS1234 / SW1234. Speaker has
a Left and Right input but only one input needs to be used. Use either a dual RCA cable or single RCA cable.
 VOLUME CONTROL
 MUTE LEVEL ADJUSTMENT
 RF—RADIO FREQUENCY INDICATOR
 AF—AUDIO FREQUENCY INDICATIOR
 CHANNEL SELECT
BUTTONS
 ASC / IR AUTO
CHANNEL SELECT
WARNING! RISK OF SHOCK! DO NOT OPEN UNIT.
NO USER SERVICEABLE PARTS INSIDE!
