PACKAGE CONTENTS
Model SW662
• One SW805A Amplifier
• Four Horn Speakers with Mounting Plates and Hardware
• One S1090 Compact Tripod
• Two S1080 Heavy Duty Tripods
• One S1960 Nylon Rolling Case
• One Wireless 16 CH UHF Microphone Transmitter (S1690T)
• Headset and Lapel Microphones
• Two 40 Ft Speaker Cables
• Two “Y” Adapters
SPECIFICATIONS
Amplifier System
• Power Output - 50 Watt RMS into 4 ohms
• AC/DC Operation
• Stereo Speaker Output
• 3.5mm Line Output
• 3.5mm Line Input
• Separate Volume and Tone Control for Line Input
• Master Volume Control
Wireless System SW805A
• Built-in UHF Selectable 16 Channel Receiver with RF Signal LED
• Wireless Range: 300 feet
• Frequency: 584 -608 MHz
Horn Bracket Assembly
• Remove bracket from horn speaker and turn it around as shown in picture and screw back onto speaker.
• Place bracket with no post on top of bracket with post.
• Align holes to match which way you want the horns to face.
• Screw mounting plates together with bolts and nuts.
• To prevent horns from spinning on plate take a small screw and locate small hole on plate. Screw into plate and
horn speaker.
• Mount on tri-pods
