Please take the time to inspect parts before beginning assembly.
Image Part # Description Image Part # Description
T47805 1pc - Tall cabinet T47806 3pc - Wall cabinets
T47808 1pc - 7-Drawer cabinet T47809 1pc - 2-Door cabinet
T47810 6pc - Pegboards T47819
2pc - Rear panels (black)
T47805-06 4pc - Tall cabinet shelves T47809-02 1pc - 2-Door cabinet shelf
T47805-09
1pc - 600mm Front baseboard
(for T47805)
T47805-10
4pc - 500mm Side baseboards
(for T47805)
GS010
2pc - 680mm Front
baseboards (for T47808 &
T47809)
T47814 1pc - MDF worktop
T47811
4pc - 1890mm Connector
posts
GS001 12pc - Adjustable legs
GS002 12pc - Fixed legs GS003 20pc - Shelf brackets
GS004 6pc - Keys GS006
24pc - M6 x 12mm Bolts
(For fixed legs [GS002])
GS007
70pc - M5 x 12mm Bolts
(for connector post [T47811])
GS011
5pc - M4 x 20mm screws
(for MDF worktop [T47814])
GS012
2pc - M4 x 30mm Screws
(for wall connector [GS013])
GS013 2pc - Wall connectors
