10 MS322 User's Guide
Part 3
The low volt ac stimulator section of the MS322 panel is depicted below. Items
referenced with circled numbers (3 – 8) are explained on the following page.
OUTPUT
RESET
INTENSITY
OUTPUT
RATE
OFF
0
15
5
10
25
20
TIME IN MINUTES
MAX
0 / RESET
FAST
SLOW
TETANIZE
PULSATION SURGE
ON
PULSE / SURGE RATE INTENSITY
