ANCHEER
11
3.3
Set front wheel into front fork. Make sure fork hanger hold onto wheel axle,
and make sure the disc put into middle of brake.
Installation And Adjustment
4. Assemble the front fender and headlight
4.1
3.4
Loosen the screw on the corresponding position of the front wheel, as shown
in the figure below. Put the fender and light in this position. Tighten the screw
that secures the fender.
Insert quick-release axle into spring and tighten screw(Quick release nut to be at
the same end as the brake).
Attention:
Tighten the quick release
with the adjustment nut
only!
Quick release
lever in the
closed position
Quick release
lever in the open
position
To Next Page
