1. Hold Glide Track (A3) with
both hands, stand the whole
machine up.
2. Insert Pedal Holder (A9) onto
Main Frame (A1), lock Pedal
Axle (#11) tight onto Main
Frame (A1) with Hex Bolt
(#83) and Hex Nut (#65),
using Spanner (#51).
3. Put the whole machine
horizontally onto the floor
after finish the locking.
1. Use Hex Bolt (#53) to lock
Pedal L (A5) and Pedal R
(A6) onto both sides of the
Main Frame (A1).
2. Screw off T Knob (#46).
Rotate Watch Stand
Assembly (#3) along the
arrow shows until the end.
Fix the position of Watch
Stand Assembly (#3) and
Main Frame (A1) with T
knob (#46) again.
