Explorer Pro Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
HAVING TROUBLE WITH YOUR SOUND SYSTEM?
CONDITION POSSIBLE SOLUTION
No Sound (power LED off) • turn POWER switch ON
• charge battery or plug in AC cord
Charge Indicator LED off • leave plugged in for 48 hours to repair battery
No Sound (power LED on) • check for output from source
• make sure all cables are completely plugged in
• turn up volume control of input used
• remove plug from speaker output if not using external speaker
output
Shortened Battery Life • charge battery fully; if battery life continues to deteriorate,
contact Anchor Audio customer service: 800.262.4671
Distorted Sound • lower system volume control
Excessive Hum or Noise • use shielded cables
• use balanced microphone
HAVING TROUBLE WITH YOUR WIRELESS SYSTEM?
(WIRELESS MODELS ONLY)
CONDITION POSSIBLE SOLUTION
No Sound (RX Indicator: ON) • set MUTE switch to on (handheld mic only)
• turn up WIRELESS volume control
• make sure mic is plugged into body pack transmitter
No Sound (RX Indicator: OFF) • push mic power button
• turn Explorer PRO POWER switch on
• make sure transmitter power switch is on
• set receiver and transmitter to same channel
• replace battery in transmitter
NEED MORE HELP? View demonstration videos on proper system setup and
operation at our website - www.anchoraudio.com
EXPLORER PRO TECHNICAL SPECIFICATIONS
Rated Power Output 75 watts AC / DC mode
Max SPL @ Rated Power 109 dB @ 1 meter
Frequency Response 80 Hz – 16 kHz
AC Power Reqs. 90 – 264 VAC, 50/60 Hz
Dimensions (HWD) 16.5” x 10.5” x 10”
(42 x 27 x 25 cm)
Weight (AC/DC) 23 lbs / 10.4 Kg
Weight (AC only) 16 lbs/ 7.25 Kg
Inputs
Microphone Lo-Z (1 k Ω) , balanced, XLR
(2 combo jacks) 12 VDC condenser mic phantom
pwr
Hi-Z
(10 K Ω) , unbal, 1/4” phone
Auxiliary Hi-Z (10 k Ω) , unbal, 1/8” & 1/4”
Sensitivity For Rated Output
Line -8.4 dBV (380 mVrms)
Mic (unbal & bal) -49 dBV (3.63 mVrms)
Outputs
Line (post fader) Lo-Z, buffered, 1/4” balanced
Speaker 4-pole Neutrik Speakon® jack
ANCHOR AUDIO CUSTOMER SERVICE
800.262.4671
FOR ADDITIONAL INFORMATION
visit www.anchoraudio.com
8
(Specifications Subject to Change Without Notice)
