ANGELUS SANITARY CAN MACHINE COMPANY
SERVICE NOTICE
Seaming Lever Cone Point Set Screw 32S826
104S816 104S816
Locknut Locknut
Seaming Roll
Adjustment Screws
28S826
* It is recommended to hold the Seaming Roll Adjustment Screw while
tightening 104S816 Locknuts.
180S Seaming Roll Lever Torque Specifications
Seaming Lever Cone Point Set Screw, number 32S826.
used to locate the Seaming Roll Lever on the Seaming Lever Shaft
should be tightened to
80 ft. lbs80 ft. lbs
80 ft. lbs80 ft. lbs
80 ft. lbs. before endplay adjustments are
made.
Locknut, number 104S816,
used to clamp & hold the Seaming Roll Adjustment Screw should
be tightened to approx.
*45 ft. lbs*45 ft. lbs
*45 ft. lbs*45 ft. lbs
*45 ft. lbs. after Seaming Rolls have been
set.
5/21/91-18000001
