09 10
2. Connect both ground wires(yellow or green
) from the junction
box and
Floodlight Camera, join the wires by using a wire nut.
If the existing ground wire has been connected to the junction box or
there's no ground wire, connect the ground wire of the Floodlight Camera
to the junction box or mounting plate directly.
1
2
3
To avoid risk of shock,injury
or death, always be cautious
when working with electricity.
Remember, do hire a
professional electrician if
you’re uncomfortable working
with electrical wiring.
3. Use wire nuts to connect Floodlight Camera wires to the rest of the wires
from junction box. Connect the white wire on the Floodlight Camera to
the white wire(neutral) from junction box. Connect the black wire on the
Floodlight Camera to the black wire(hot) from junction box.
To avoid risk of shock, injury or death, always be cautious when
working with electricity. Remember, do hire a professional
electrician if you’re uncomfortable working with electrical wiring.
