Anova MG246 - Page 112

14. TECHNICAL SPECIFICATIONS
Model
MG246
MG252
MG262
Displacement:
45 cm
3
52 cm
3
61.5 cm
3
Maximum motor power:
1.7 kW
2.1kW
2.85kW
Fuel:
Mixture (25 Unleaded Gasoline: Two Cycle
Oil 1)
Fuel tank capacity:
550 ml
550 ml
Chain oil:
SAE 10-30
SAE 10-30
Oil tank capacity:
260 ml
260 ml
Carburetor:
diaphragm
Idle speed range:
3000± 300 min
-1
Maximum speed with cutting system
10300 min
-1
Maximum chain speed:
21 m / s
21 m / s
Ignition system:
Electric coil
Spark plug:
BOSCH L8RTF / CHAMPION RCJ7Y
Oil feeding system:
Mechanical oil pump with adjustment
Pinion Teeth x Tilt:
6T × 9.525mm (0.325in)
Dry weight (without guide bar and chain, empty tanks):
6.4 kg
6.4 kg
6.7 kg
Declared sound power level LWAd
117 dB (A)
117 dB (A)
Sword
Anova
Kind:
Rolled with pinion
Size:
18 "
18 "
20”
Cutting length:
45 cm
45cm
51cm
Saw chain
Kind:
Anova 18 "
Anova 20”
Chain pitch:
8.255 mm (0.325 in)
Caliber:
1.47mm (0.058in)
Specifications are subject to change without notice.
