DESCRIPTION
The product converts sunlight to direct voltage.
The product is intended for charging
12 V batteries.
1. Solar panel 50 W
2. Charging regulator 7 A/12 V
3. Cable for battery clips
FIG. 1
USE
IMPORTANT:
• Do not stand or walk on the solar panel.
• Do not lift the panel with the solar cells.
• Grip the slot between the solar cells as
shown in the diagram.
FIG. 2
HOW TO USE
1. Unfold the solar panel.
2. Place the unfolded solar panel at a direct
angle to the sun, so that it absorbs as
much solar energy as possible. Support
the panel if necessary so that it stands
rm and at the correct angle to the sun.
– For best output, make sure that no
shadow falls on the solar cells.
A = Best, B = Acceptable, C = Wrong
FIG. 3
3. Connect the solar panel to the charging
regulator and connect the battery clip
leads to the battery.
A B C
(W top) (A) Recommended
50 W 2.77 A 7 A/12 V
A = Total output
B = Charging current
C = Charging regulator
SAFETY INSTRUCTIONS
• The solar panel generates voltage when
exposed to light. Follow all the relevant
electrical safety regulations.
• The product must only be installed and
maintained by suitably qualied persons.
• Pay attention to high voltages when
connecting solar panels.
• Avoid scratching or otherwise damaging
the back of the panel.
• Protect the product from dust and dirt for
best functionality.
• Use and store the product in a dry and
well ventilated place.
• Do not use in ammable and/or explosive
environments.
• Stop using immediately if any wires are
loose or electrical components are
exposed.
SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.
TECHNICAL DATA
Solar cell type Monocrystalline*
Output (max) 50 W (± 5%) at 18.0 V
Operating temperature –10°C to +85°C
Size folded up 368 x 325 x 50 mm
Size unfolded 1598 x 325 x 5 mm
* With high eciency.
