Anslut 014399 - Safety Instructions; Technical Data

EN
28
USB 5 VDC, 2 A
Ambient temperature, operation 35 to 50°C
Protection rating IP20
Size, unfolded 1666 x 492 x 5 mm
Size, folded 387 x 492 x 40 mm
Battery cable 3 m
Connection cable 1 m x 2.5 mm
Weight 10.4 kg
014400
Solar cell Monocrystalline
Rated voltage 12 VDC
Charging regulator current* 20 A
Output* 150W
USB 5 VDC, 2 A
Ambient temperature, operation -10 to 85°C
Protection rating IP20
Size, unfolded 1798 x 650 x 5 mm
Size, folded 420 x 650 x 40 mm
Battery cable 3 m
Connection cable 1 m x 2.5 mm
Weight 14.5 kg
* In ideal conditions in strong sunlight.
DESCRIPTION
Folding solar panel for conversion of sunlight to
DC current, intended to be used together with
charging regulator to charge 12 V batteries or
supply 12 V equipment with power.
PROPERTIES
• Monocrystalline solar cells with high
eciency and long life span.
• Transparent protective lm, high light
permeability, high corrosion resistance,
and long life span.
• Controller with USB port.
• Cable with cable lugs for connection to
12 V battery (3 m). The solar panel is
mounted either suspended or sloping
SAFETY INSTRUCTIONS
• Read these instructions before installing
and connecting the product.
• Do not dismantle the product or attempt
to modify, or repair it.
• Install an external fuse or miniature
circuit-breaker according to requirements
and local regulations.
• Disconnect the solar panel and the fuse/
circuit breaker at the battery before
connecting or moving the charge
controller.
• Check that the power connections are
rmly tightened to minimise loss of power
and the risk of overheating.
• Only charge batteries with data that
matches the rated data of the charge
controller.
• One or more batteries can be connected.
• Risk of electric shock – both the solar
panel and the connected electrical
equipment can generate high voltages
when the charge controller is working.
SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.
TECHNICAL DATA
014399
Solar cell Monocrystalline
Rated voltage 12 VDC
Rated current* 10 A
Output* 100W
