9
Deutsch | English | Fraais | Español | Português | Svenska
Italiano | Nederlands | Dansk | Suomi | Norsk
Deutsch | English | Français | Español | Português | Svenska
Italiano | Nederlands | Dansk | Suomi | Norsk
1,44V Zinc-Air-button cells: 10 / 13 / 675 / 312
3V Lithium-button cells: CR1025 / CR1216 / CR1220 / CR1616 / CR1620
CR1632 / CR2016 / CR2025 / CR2032 / CR2320
CR2330 / CR2354 / CR2430 / CR2450 / CR2477
CR3032
3V Lithium-Photo-Batteries: CR2 / CR123 (A)
3,6V/3,7V Li-Ion-rechargeable batteries: 14500 / 14650 / 16340 / 17500 / 18500
18650 / 22650 / 26650
LCD-DISPLAY(2):
“CALC”: Measurement (Calculation)
“80 %”: Cell capacity in 10%-steps.
“1.53 V”: Cell voltage in volts.
“Err”: Error.
OPERATION:
The device requires a 9V battery for power (supplied). To fit, open the battery
compartment on the back of the device, and snap the battery into the appropriate
contacts. Close the battery compartment.
Push the button “Self-test” (1) for approximately two seconds to check the capa-
city of the inserted battery.
Because a nearly empty 9V battery may affect the test result, we recommend re-
placement of the battery if the capacity is ≤ 20%!
HOW TO MAKE MEASUREMENTS:
There are no settings necessary to test cells.
1. Select the appropriate test terminal for the battery under test (see table (3)
2. Place the battery on the test terminals, paying attention to the polarity.
(Both contacts must be connected) An additional test pin (4) should be used
if testing cylindrical cells. This test pin must connect to the minus pole of
the cylindrical cell!
3. Please connect the battery for approximately two seconds. The display
shows “CALC”
4. The capacity of the cell will be shown in 10 % steps for approximately
two seconds.
5. The voltage of the cell will be shown in volts for approximately two seconds.
IMPORTANT TIPS FOR BETTER TESTING:
§ When testing cylindrical cells please push the test pin with high pressure to the
battery to guarantee a correct measurement.
§ Please ensure that the contacts of the test terminals and the contacts of the cells
are clean.
§ With a new battery it is possible that the full capacity may not be shown.
§ The cell needs to “wake up”. Please test again.
IN CASE OF PROBLEMS:
Err”:
§ Incomplete measurement. Please connect the cell for approximately two seconds.
§ With a deeply discharged cell the display may switch from “CALC” to “Err”.
