Pressing and holding the "+" or "-" key for more than 1 second
will increase the speed of value change
Adjustmemt buttons - Use "+" and "-" keys for changing values
EPA should be used when adjustments are being made to left/right
steering angle and throttle high/brake side during linkage setup.
EPA adjusts the maximum angle causing a different turning radius.
End Point Adjustment
EPA is used to adjust the maximum servo travel for each channel.
Always check linkages while adjusting EPA.
Adjustadle Throttle Limiter
ALT trim adjusts the amount of overall brake throw the model will have.
Thus when adjusting throttle using EPA , the ALT must be considered.
EPA range
- 0 - 120% for each channel and direction
Left side steering
Warning
The servo may malfunction and the model may lose control if unreasonable force is applied to the servo
horn during steering operaton.
Warning!
Do not over apply EPA as this will cause binding
to occur and will result in servo failure.
Maximum EPA value at the contact point
Right side steering.
Forward side throttle
return to the initial screen.
Brake side throttle
9
ENGLISH
TRANSMITTER FUNCTIONS
