AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96 5
Trouble Operation,
continued
Pressing <Alarm Silence> when only troubles exist, gives the same result as
pressing <Acknowledge/Step>. The Alarm Silenced LED does not light
unless an alarm exists in the system.
If multiple trouble conditions exist in the system, the optional LCD and
optional LCD-80 displays automatically step through each trouble event
every 3 seconds in the following order:
1) Alarms, in order of address;
2) Supervisory, in order of address; or
3) Troubles, in order of address.
Press <Acknowledge/Step> and the display stops on the current trouble
event for 1 minute. Press <Acknowledge/Step> to continue.
The system goes into Fire Alarm mode when the control panel detects a fire
alarm. During Fire Alarm mode, the control panel does the following:
 produces a steady audible tone;
 activates the System Alarm relay (MPS-400, TB3) and flashes the System
Alarm LED;
 displays Alarm in the status banner on the LCD display;
 latches alarms so they cannot clear until the alarm initiating device
returns to its normal condition and the operator resets the control panel;
 initiates any Control-by-Event actions;
 starts timers (Silence Inhibit, Auto Silence); and
 activates the general alarm zone (Z00).
Fire Alarm
Supervisory signals cause the control panel to do the following:
 produce a warbling audible tone;
 turn on the Supervisory relay (MPS-400, TB5) and flash the Supervisory
LED;
 display Active in the status banner on the control panel.
 turn off the panel sounder for all Silenced alarms; and
 prevent timers from starting.
Figure 7: Typical Supervisory Signal display
Supervisory Signal
 Supervisory signalslike fire alarmscan use CBE actions.
 Supervisory signals do not sound alarms or reactivate silenced alarm
CBEs.
 Supervisory circuits can also cause circuit troubles, which operate like
trouble signals.
Figure 6: Fire Alarm Display
ALARM:PULL STATION I.C.U. WEST WING
VISITORS LOUNGE 11:58PM 10/31/95 M101
Status banner Alarm
You can program
Supervisory signals as
Tracking or Latching.
ACTIVE TAMPER I.C.U. WEST WING
VISITORS LOUNGE 12:01A 11/01/95 M101
Status banner Active
