4 AUTOPULSE IQ-396X Operations Doc. 50403:B 07/22/96
The system operates in Normal mode when no alarms or troubles exist. In
Normal mode, the control panel displays a system message as follows:
3. Operating Modes
In Normal mode, the control panel does the following functions at regular
intervals:
 Polls all Signaling Line Circuit (SLC) devices and the four NACs to check for
valid replies, alarms, troubles, circuit integrity, and so on.
 Checks power supply troubles and batteries every 10 seconds.
 Sends a supervisory query on the LCD-80 and verifies proper response.
 Refreshes the LCD and the optional LCD-80 display and update time.
 Scans the keypad for a System Reset or an Enter key press.
 Performs a detector automatic test operation.
 Tests system memory.
The system goes into Trouble mode when the control panel detects an electrical
or mechanical fault. With no alarms, a control panel in Trouble mode does the
following:
 produces a pulsed audible tone;
 flashes the System Trouble LED;
 activates the trouble relay (MPS-400, TB3); and
 sends a message to the LCD display, an optional LCD-80, an optional printer,
and the history file. Figure 4 shows a typical Trouble message:
1) Press <Acknowledge/Step> to silence the panel sounder and switch the
System Trouble LED from flashing to steadyregardless of the number of
troubles, alarms, and supervisory signals.
2) Pressing <Acknowledge/Step> while at least one new alarm or trouble
exists, causes the control panel to send an Acknowledge message to the
history file and an optional printer.
If the trouble clearsbefore or after pressing <Acknowledge/Step>the
control panel sends a Clear Trouble message to the printer. Figure 5 shows a
sample Trouble Message:
Addressable CMX
modules report both
open and short circuit
messages.
If all troubles clear and no supervisory or fire conditions exist, the control panel
does the following:
 returns to Normal mode;
 sends an All Systems Normal message to the LCD display, the history file, an
optional LCD-80, an optional printer; and
 restores troubles automatically even if troubles are not acknowledged.
Figure 4: Trouble Message
Trouble Operation
Normal Operation
YOUR CUSTOM FORTY CHARACTER MESSAGE HERE
ALL SYSTEMS NORMAL 11:30A TUE 06/10/95
TROUBL PULL STATION I.C.U. WEST WING
Z1 INVALID REPLY 11:45PM TUE 10/31/95
Type of trouble
Type of device
Type of event
(trouble)
Software zone
assigned (Zone 1)
Custom descriptor for
this device location
Time and date
TROUBL CONTROL MODULE ADDRESS 21 Z00 OPEN CIRCUIT 08:10A 08/20/95 M21
TROUBL CONTROL MODULE ADDRESS 22 Z00 OPEN CIRCUIT 08:12A 08/20/95 M22
Figure 5: Sample Trouble Message
Figure 3: All Systems Normal Message
