Anysecu W2plus - Technical Specifications; RF Parameters; GPS and Data Speed

OS
Android 7.0
Screen Size
4.5 inches, 480x320mm
Language
Multi languages
Frequency band
EU version
TDD-LTE: Band38/40/41
FDD-LTE: Band1/3/5/7/8/20
WCDMA: Band 1/2/5/8
GSM/GPRS/EDGE: Band2/3/5/8
US version
FDD-LTE:Band1/2/4/5/7/12/13/17/
28a/28b
WCDMA: Band 1/2/4/5
GSM/GPRS/EDGE: Band2/5
Antenna
1)WCDMA/GSM with external antenna
2)GPS antenna with external antenna
3) BT/WIFI antenna is built-in FPC antenna
GPS
GPS/AGPS
USB
USB 2.0
SIM Type
Standard sim card
Dimension
170x80x85mm
Weight
380g
Working Voltage
DC 10-24V
Working Temperature
-30℃ to +75℃
Platform Tested
RealPTT, Zello
Talk Range
Limitless in WCDMA/GSM Coverange
RF Parameter
Maximum Output Power
WCDMA 2100/1900/900/850MHz:
Power class 3 (+24dBm +2.5/-1.5dBm) GSM/GPRS 850MHz/900MHz:
Power class 4 (+33dBm +2.5/-0.5dBm) GSM/GPRS 1800MHz/1900MHz:
Power class 1 (+30dBm +2.5/-0.5dBm)
Receiving Sensitivity
WCDMA 2100: ≤-108dBm
WCDMA1900: ≤-109dBm
WCDMA900: ≤-109dBm
WCDMA850: ≤-109dBm
GSM850/900/1800/1900: ≤-107dBm
GPS
GPS
GPS Positioning, Support A-GPS function,1.57542GHz;
Sensitivity
Catch -144dBm, Track -159dBm
Technical Sensitivity
Data Speed Rate
GSM CS: UL 9.6kpbs/ DL 9.6kpbs GPRS: Multi-slot Class 10
EDGE: Multi-slot Class 12
WCDMA CS: UL 64kpbs/ DL 64kpbs WCDMA PS: UL 384kpbs/ DL
394kpbs
Protocol
HSDPA/WCDMA/EDGE/GPRS/GSM
we endeavors to achieve the accuracy and completeness of this manual, but it is still not perfect for
any possible omissions or printing errors. All the above functions and design are subject to be updated
without prior notice due to continuous development.
