I/O data
5-5
5.1.5. Command output
Module name
ASLINK command output
b15
b14
b13
b12
b11
b10
b9
b8
b7
b6
b5
b4
b3
b2
b1
b0
Command output 4
words
-
-
-
P
-
-
-
-
-
-
-
-
-
-
N
M
Target ID of write operation
Parameter number to be written
Value to be written
Name
Content
M
Error flag clear
Switching this bit from OFF to ON clears the latest error code
and error occurrence ID in the input area.
N
Automatic address recognition
command in the ASLINK system
Switching this bit from OFF to ON executes the automatic
address recognition process.
P
Parameter write command
Switching this bit from OFF to ON writes the value to be
written to the parameter at the parameter number to be
written on the slave unit with the target ID of write operation.
Target ID of write operation:
The ID number of the target slave unit of which a parameter is written
Parameter number to be written:
The target parameter number (1–19) to which the value is written
Value to be written:
The value to be written to the parameter
