21.5" LCD Color Monitor AOC 2236Vwa
21
7.2 Power Board
!
R931
NC
R906
100KOHM +-5% 2WS
D905 NC / 31D Q06F C3
D901
NC/SR5150
1 2
VOL
!
936SW/2036S
+5V
C908
0.22UF
C909
NC/0.22uF/275V
DIM
HS3
HEAT SINK(D906_5V/2.5A)
1
2
R907
1K 1/10W 1%
F901
FUSE
PWPC9921MHD1/PWPC9821AHD1/PW PC 9921MHD2
1
Custom
23Tuesday , March 17, 2009
715G2892-1-3
OD M MOD EL
01.POWER
G2892-1-3-X-1-090317
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔
瓜
絪
腹
D904
FR103
R910 100 OHM 1/4W
C927
0.047uF
+
C931
NC
NC
R934
NC
R901
620K OHM 1/4W
F903
NC
R918
10K 1/10W 1%
2008-11-22
R917
10R 1/4W 5%
-
+
BD901
KBP208G
2
1
3
4
C903
1000PF/250VAC
R904
220 OHM 2W
R924
0.39 OHM 2W +-5%
2008-12-01
+
C921
NC
U903
KIA431A-AT/P
Q904
KTD1028
C900
0.0022UF
HS2
NC/ HEAT SINK(D906_5V/4A)
1
2
F801
0R05 1/4W 5%
2008-12-01
!
C912
0.1uF/ 25V
R923
220 OHM 1/4W
D906
FMW-2156
1
2
3
2008-12-01
!
D907
IN4148
C938
NC
2008-12-01
D902
SB5150
1 2
L901
30mH
1
4
2
3
FB901
BEAD
12
!
GND1
GND
1
2
U901
LD7576
1
2
3
4 5
6
7
8
CT
COMP
CS
GNDOUT
VCC
NC
HV
R933
NC
T901
POWER X'FMR
6
8
5
2
1
11
10
12
9
7
4
R935
NC
+
C907
100UF450V
R921
NC/ 100K 1/10W 1%
!
ON/OFF
D903
FR107
NR 901
NTCR
+
C922
470uF 16V
!
R928
1K 1/10W 1%
+
C925
1000uF/16V
R908
10K OHM 1/4W +-5%
L906
D908
NC/IN4148
U902
PC123X2Y FZOF
12
43
C923
0.001uF
R930 100 OHM 1/4W
+5V1
C902
1000PF/250VAC
L907
MUTE
C914
470pF
R919
150R 1/8W 5%
R916
3.65K OHM 1% 1/10W
HS1
HEAT SINK(Q901)
1
2
C926
0.1uF/16V
+
C918
1000uF 25V
+
C920
1000uF 25V
R932
NC
C911
1500PF2KV
R903 100 OHM 1/4W
R900
620K OHM 1/4W
R913
1.5 OHM 1/4W +-5%
!
ZD901
MTZ J T-72 16B
1 2
R909 100 OHM 1/4W
!
C937
0.01uF/2KV
C924
0.1uF/16V
R925
2.43K OHM 1% 1/10W
R902
620K OHM 1/4W
R920
1K 1/10W 1%
!
C915
!
R905
470R 1/10W 5%
+
C913
22uF/50V
C916
0.001uF
R929 100 OHM 1/4W
+5V
CN 901
SOCKET
12
3
R914
43.2K OHM 1% 1/4W
!
CN 902
Wire Harness
1
2
3
4
5
6
7
8
9
Q901
FMA07N65GX
R912 100 OHM 1/4W
2008-12-01
+14.5V
C917
0.001uF
!
F902
FUSE
