AOC 2236VWA Service Manual

21.5" LCD Color Monitor AOC 2236Vwa
44
C801 065G0805473 32 CHIP 0.047UF 50V X7R
C917 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R
C916 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R
C803 065G1206104 32 CHIP 0.1UF 25V X7R 1206
D806 093G 64 42 PP BAV70 SOT-23
D807 093G 64 42 PP BAV70 SOT-23
D808 093G 64 42 PP BAV70 SOT-23
ZD802 093G 6432S 1N4148W
ZD803 093G 6432S 1N4148W
D803 093G 6433S DIODE BAV99 SEMTECH
PW9C41AHD2AI POWER BOARD FOR AI
C503 065G0603104 12 CER2 0603 X7R 16V 100N P
C501 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
C502 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
FB501 071G 56K121 M CHIP BEAD
715G3501 2 USB BOARD PCB
U401 056G 562574 IC TSUMU58EHL-LF-1
U703 056G 563 31 IC AZ1117D-1.8-E1
U701 056G 585 4A IC AP1117E33L-13
U107 056G 662502 IC ESD AZC199-04S SOT23-6L
U106 056G 662502 IC ESD AZC199-04S SOT23-6L
U105 056G 662502 IC ESD AZC199-04S SOT23-6L
U104 056G 662502 IC ESD AZC199-04S SOT23-6L
U103 056G 662502 IC ESD AZC199-04S SOT23-6L
U402 056G1133129 IC EN25F20-100GCP 2Mb SOP-8
U102 056G1133918 IC AT24C02BN-SH-T 8-SOIC
U101 056G1133918 IC AT24C02BN-SH-T 8-SOIC
Q701 057G 417 12 T KEC 2N3904S-RTK/PS
Q302 057G 417 12 T KEC 2N3904S-RTK/PS
Q405 057G 417 13 T KEC 2N3906S-RTK/PS
Q401 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q301 057G 763 1 A03401 SOT23 BY AOS(A1)
R414 061G0402000 RST CHIP MAX 0R05 1/16W
R418 061G0402000 RST CHIP MAX 0R05 1/16W
R419 061G0402000 RST CHIP MAX 0R05 1/16W
R423 061G0402000 RST CHIP MAX 0R05 1/16W
R434 061G0402000 RST CHIP MAX 0R05 1/16W
R452 061G0402000 RST CHIP MAX 0R05 1/16W
R134 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R132 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R131 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R130 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R129 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R128 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R127 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R126 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R101 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R119 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R118 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R117 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R115 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
