AOC 2236VWA Service Manual

21.5" LCD Color Monitor AOC 2236Vwa
47
C105 065G0402509 31 CHIP 5pF 50V NPO
C109 065G0402509 31 CHIP 5pF 50V NPO
C113 065G0402509 31 CHIP 5pF 50V NPO
C303 065G0603105 22 CHIP 1UF 25V X7R 0603
C402 065G0805475 A5 0805 4.7UF +-10% 10V X5R
FB301 071G 56K121 M CHIP BEAD
FB410 071G 56V301 B CHIP BEAD FCM2012VF-301T07 bullwill
FB401 071G 56V301 B CHIP BEAD FCM2012VF-301T07 bullwill
FB402 071G 56V301 B CHIP BEAD FCM2012VF-301T07 bullwill
FB404 071G 56V301 B CHIP BEAD FCM2012VF-301T07 bullwill
FB110 071G 59G301 CHIP BEAD 300OHM
FB105 071G 59G301 CHIP BEAD 300OHM
FB104 071G 59G301 CHIP BEAD 300OHM
FB101 071G 59K190 B 19 OHM BEAD
FB102 071G 59K190 B 19 OHM BEAD
FB103 071G 59K190 B 19 OHM BEAD
D108 093G 64 42 PP BAV70 SOT-23
D104 093G 64 42 PP BAV70 SOT-23
ZD104 093G 39GA01 T RLZ5.6B
715G3329 1 2 MAIN BOARD PCB
CN901 006G 31500 EYELET
PT801 006G 31502 1.5MM RIVET
IC903 056G 158 10 T IC AS431AZTR-E1 TO-92
Q904 057G 761 16 TRA KTD1028 KEC
R906 061G152M10452T RST MOFR 100KOHM +-5% 2WS
R924 061G152M39852T RST MOFR 0.39 OHM +-5% 2WS
R904 061G152M75052T RST MOFR 75OHM 5% 2WS
R828 061G212Y62552T6W56 RST MGFR 6.2MOHM +-5% 1/2W
C911 065G 2K152 2T6921 CAP CER 1500pF K 2KV Y5P
C920 067G 2046812KT CS CAP 680uF 10V 8*11 mm
C913 067G215Y2207KT
CAP 105℃ 22UF M 50V KINGNICHI
FB902 071G 55 9 T FERRITE BEAD
FB602 071G 55 9 T FERRITE BEAD
FB901 071G 55 29 FERRITE BEAD
F901 084G 56 4 B FUSE 4A 250V
F902 084G 56 4 B FUSE 4A 250V
F903 084G 56 4 B FUSE 4A 250V
ZD901 093G 39A0852T GDZJ18B
D903 093G 6026T52T RECTIFIER DIODE FR107
D904 093G 6038T52T FR103
D801 093G 64 1152T 1N4148
D907 093G 64 1152T 1N4148
J902 095G 90 23 JUMPER WIRE
J901 095G 90 23 JUMPER WIRE
J823 095G 90 23 JUMPER WIRE
J822 095G 90 23 JUMPER WIRE
J821 095G 90 23 JUMPER WIRE
J820 095G 90 23 JUMPER WIRE
J604 095G 90 23 JUMPER WIRE
J605 095G 90 23 JUMPER WIRE
J606 095G 90 23 JUMPER WIRE
