HDMI Input Signal Reference Chart
When connecting the PC to this TV with HDMI, set the PC output signal according to the table below.
HD
Default PC mode
Standard Resolution Horizontal Frequency(kHz) Vertical Frequency(Hz)
IBM VGA 640 x 480 31.469 59.94
VESA 800 x 600 37.879 60.317
VESA 1024 x 768 48.363 60.004
VESA 1360 x 768 47.712 60.015
VESA 1920 x 1080 66.587 60
VESA 1600 x 1200 75 60
FHD
Default PC mode
Standard Resolution Horizontal Frequency(kHz) Vertical Frequency(Hz)
IBM VGA 640 x 480 31.469 59.94
VESA 800 x 600 37.879 60.317
VESA 1024 x 768 48.363 60.004
VESA 1360 x 768 47.712 60.015
VESA 1280 x 1024 63.981 60.02
VESA 1920 x 1080 66.587 60
VESA 1600 x 1200 75 60
*Only support the timing which is listed.
Video Input Signal Reference Chart
1. Connect the component signal or HDMI port of video device to your TV set and set up the output signal of the video device in
accordance with table below.
2. If your computer display card supports signals of video format then you can set up following output signal.
Default Component or HDMI Mode
Standard Resolution Vertical Frequency(Hz)
SD 720 x 480i 59.94 / 60
SD 720 x 480p 59.94 / 60
SD 720 x 576i 50
SD 720 x 576p 50
HD 1280 x 720p 50 / 59.94 / 60
FHD 1920 x 1080i 50 / 59.94 / 60
FHD 1920 x 1080p 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
Video systems supported by the TV, video modes
NTSC M,PAL M,PAL N.
Standard Definition Interface
You can also enjoy traditional program by using a DVD player or VCR Player. Connect this equipment to your TV via the
Composite Input on the back of your TV.
