AOC 931Fwz User Manual

19" LCD Color Monitor AOC 931Fwz
43
11. BOM List
T97MMTNQW6A16N
Location Part No. Description
Remark
001G6022 1 SCREW
026G 800504 3 BARCODE LABEL FOR 4
040G 154501 1 HI-POT GND LABEL
040G 58162461A EPA LABEL
045G 77500 BARCODE RIBBON
045G 77501 BARCODE RIBBON
051G6001 2 DESICCANT
052G 1150 C INSULATING TAPE
052G 1186 SMALL TAPE
052G 1207 A CONDUCTIVE TAPE 45mm *25mm *0.08mm
052G 1211 B AL TAPE
052G6019 1 INSULATING TAPE
052G6026 1 MESH PRINTTING PAPER
052G6026 2 MESH PRINTTING PAPER
070GHDCP500HDC MSTAR-HDCP HDCP CODE
078G 477500 Y SPK 4 OHM 2W 54X17mm 380 420 SUNLINK
089G 17356C553 AUDIO CABLE 1800MM
089G 725CAA DB D-SUB
089G1745HAA AC DVI CABLE
089G179E30N513 FFC CABLE
089G402A15NIS1 POWER CORD
E09501 095G801410D598 WIRE HARNESS 10P(PH)-4P(PH)+6P(PH)
2nd source
E09501 095G801410X598 WIRE HARNESS 10P(PH)-4P(PH)+6P(PH)
0M1G 130 5120 SCREW
0M1G1730 6120 SCREW,42-D020523
0M1G1730 6120 SCREW,42-D020523
0M1G1740 12 47 CR3 SCREW
705GQ834167 19" LCD STAND BASE ASS'Y
0Q1G 330 5 47 CR3 SCREW
Q12G6600 6 FOOT
Q33G0190AEP 1M0100 STAND COVER F
Q33G0191AEP 1M0100 STAND COVER B
Q34G0359AEP 1M0100 STAND
Q34G0360AEP 1M0100 BASE
Q37G0072012CKD HINGE
E750 750GLM90Z1112N PANEL M190Z1-L01 C1 NB CMO
E750 750GLM90Z1122N PANEL M190Z1-L01 C1 NB CMO
2nd source
CBPC8MMTA1Q2 CONVERSION BOARD
040G 45762412B CBPC LABEL
CN402 033G3802 6 WAFER
CN701 033G3802 9 WAFER 9P RIGHT ANELE PITCH
CN301 033G801930F CH JS CONNECTOR
R708 061G152M159 64 6.2 OHM 2W 5% MOF
C402 067G 3151007KV ELCAP 10UF M 50V 105℃ KINGNICHI
C419 067G 3151007KV ELCAP 10UF M 50V 105℃ KINGNICHI
C706 067G 3151014KV EC 105℃ CAP 100uF M 25V
C707 067G 3151014KV EC 105℃ CAP 100uF M 25V
C305 067G 3151014KV EC 105℃ CAP 100uF M 25V
C704 067G 3151014KV EC 105℃ CAP 100uF M 25V
CN101 088G 35315F H D-SUB 15PIN
CN102 088G 35424F N DVI 24PIN CONN F WITH SCREWS
X401 093G 22 53 J 14.31818MHZ/32PF/49US
