Connecting the Monitor
Cable Connections In Back of Monitor and Computer:
1. Microphone in
2. Earphone (Combined with Microphone)
3. USB3.2 Gen1 downstream + fast charging
4. USB3.2 Gen1 downstream
(
Reex Latency Analyzer
)(
Green port
)
5. USB3.2 Gen1 upstream
6. AC in
7. HDMI1
8. HDMI2
9. DP
10. Quick Switch port
11. Microphone out (Connect to PC)
12. Luminance (Light) sensor
Connect to PC
1. Connect the power cord to the back of the display rmly.
2. Turn off your computer and unplug its power cable.
3. Connect the display signal cable to the video connector on the back of your computer.
4. Plug the power cord of your computer and your display into a nearby outlet.
5. Turn on your computer and display.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
To protect equipment, always turn off the PC and LCD monitor before connecting.
