27
Specification
General Specification
Panel
Model name AG493QCX
Driving system TFT Color LCD
Viewable Image Size 124 cm diagonal
Pixel pitch 0,3114mm(H) x 0,3114mm(V)
Video HDMI /DP
Display Color 16.7M Colors
Others
Horizontal scan range
30k-170kHz
Horizontal scan Size(Maximum)
1195.776
mm
Vertical scan range
48-120Hz (HDMI)
48-144Hz (DP)
Vertical Scan Size(Maximum)
336.312
mm
Optimal preset resolution
3840x1080@60Hz
Max resolution
3840x1080@60Hz(HDMI)
3840x1080@144Hz(DP)
Plug & Play VESA DDC2B/CI
Connector HDMI2.0X2/DP1.4X2/USB 3.2 Gen1X4/USB Up/Earphone out
Power Source 100-240V~, 50/60Hz, 3A
Power Consumption
Typical(default brightness and contrast) 80 W
Max. (brightness = 100, contrast =100) ≤150W
Standby mode ≤ 0.5 W
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
