AOC D32W931

86
LC42H053
Item Description
1 REAR COVER
2 BEZEL
3 BASE
4 KEY COVER
5 KEY BUTTON
6 IE LENS
7 LED LENS
8 HINGE-A'SSY
9 PANEL
10 BKT-VESA-BTM
11 BRACKET
Item Part No. Description Qty
12 BKT-PB 17 Q01G6145 1 SCREW(BKT-BASE/BASE) 4
13 BKT-STAND 18 001G6021 1 SCREW(SPEAKER/BEZEL) 4
14 BKT-MB-L 19 0M1G 930 6 47 CR3 SCREW(MAIN BOARD/BKT/PANEL/REAR COVER) 4
15 BKT-MB-R 20 0M1G 940 6120 SCREW(BKT/PANEL) 14
16 BKT-BASE 21 0M1G 940 8 47 CR3 SCREW(REAR COVER) 4
31 RUBBER FOOT 22 0M1G1730 8120 SCREW(MAIN BOARD/BKT/POWER BOARD) 9
32 BKT-FIX-PANEL 23 0M1G1740 8120 SCREW(BKT/HINGE-A'SSY) 2
34 PCB_BKT_TOP 24 0M1G1740 14120 SCREW(HINGE-A'SSY) 2
35 CABLE TIE 25 0Q1G 130 8 47 CR3 SCREW(BKT-BASE/BASE) 6
36 BKT-FIX 26 0Q1G 930 8 47 CR3 SCREW(BKT/PANEL) 4
37 BKT-FIX-S 27 0Q1G 940 16 47 CR3 SCREW(BKT-FIX-S/PANEL/REAR COVER/BEZEL) 14
38 DECO_BEZEL 28 0Q1G 940 30 47 CR3 SCREW(REAR COVER/BEZEL) 4
39 RUBBER 29 0Q1G1030 6120 SCREW(IR BOARD/BEZEL) 1
