AOC D32W931

87
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice.
Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information.
D26W931 E269STNS4WB36N
Location Part No. Description Remark
002F7015 1 NUT
004F081510T 00 WASHER
004F122515M 00 WASHER
004F1808104 00 WASHER
004F1808104 01 WASHER
004F180820M 00 WASHER
028F0840110 SHAFT
040G 581689 4A BARCODE LABEL FOR 1
045G 77500 BARCODE RIBBON
045G 77501 BARCODE RIBBON
052G 1186 SMALL TAPE
052G 2191 A PAPER TAPE
SP01 078G120A501 V SPK 8 OHM 12W 138X45 VECO 2nd source
SP01 078G120A501 Y SPK 8 OHM 12W 138X45 SUNLINK
085T 583103 GASKET
089G 725CAA DB D-SUB CABLE
E08901 089G424A15N CX AC POWER CORD 1500MM BRAZIL REG.
E08901 089G424A15N IS AC POWER CORD 1.5M FOR BRAZIL REG. 2nd source
ECN700 095G801312D664 HARNESS 12P-12P 120MM
ECN600 095G8014 4L614 HARNESS 4P-B&R+B&W 500/380MM
ECN600 095G8014 4W614 HARNESS 4P-B&R+B&W 500/380MM 2nd source
ECN903 095G801414DH82 HARNESS 14P(PH)-13P(A2008H) 230MM
ECN903 095G801414XH82 HARNESS 14P(PH)-13P(A2008H) 230MM 2nd source
ECN704 095G8018 3DJ35 LVDS CABLE 30P-40P 320MM 2nd source
ECN704 095G8018 3XJ35 LVDS CABLE 30P-40P 320MM
0M1G 930 6 47 CR3 SCREW
0M1G 940 16 47 CR3 SCREW
0M1G1140 6120 SCREW
0M1G1730 8120 SCREW
0M1G1730 10120 SCREW 42A9930016
0Q1G 930 8 47 CR3 SCREW
0Q1G 940 12 47 CR3 SCREW
0Q1G 940 16 47 CR3 SCREW
0Q1G 940 16 47 CR3 SCREW
0Q1G1840 8120 SCREW
705TQ949001 COMSUPTIVE ASS'Y-A4
705TQA34E20 REAR COVER ASS`Y
P34T0291ADT 1A0100 REAR COVER TV26W-9C1-9C1
Q15T0257101CKD 26BKT-VESA-BTM
Q34T7112ADT 1A0100 COVER-REAR-IO
705TQA34E21 STAND ASS`Y
0Q1G 130 8120 SCREW 42A9930011
P15T0439202CKD BKT_BASE_PLATE
P34T0305ADT 1L0100 BASE
Q12G6300 25 3 RUBBER
705TQA34E35 BEZEL ASS`Y
0Q1G1030 8120 SCREW
