5. Block Diagram
5.1 Main board
CRYSTAL 14.31818MHZ
(X401)
FLASH ROM
MX25L2026DM1I
(U403)
Scalar IC RTD2486HRD-GR
(Include ADC, OSD, MCU)
(U401)
Panel Interface
(CN402)
Key Control Interface
(CN403)
D-Sub Connector
(CN101)
DVI Connector
(CN102)
Phone Jack
(CN602)
HDMI Connector
(CN103)
DP Connector
(CN104)
AUDIO
APA2606NAI
(U601)
Speaker
(CN601)
Phone Jack
(CN603)
