AOC E2770SH User Manual

60
G2770PQU/G2770PF
Panel
Model name
G2770PQU/G2770PF
Driving system
TFT Color LCD
Viewable Image Size
68.6cm diagonal
Pixel pitch
0.311mm(H)X0.311mm(V)
Video
R, G, B Analog lnterface & Digital Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
330MHz
Resolution
Horizontal scan range
30 kHz - 83 kHz
Horizontal scan range
30 kHz - 160 kHz for DVI (dual link) ; DP only
Horizontal scan range G2770PF
160 kHz - 160 kHz for DP only
Horizontal scan Size(Maximum)
597.6mm
Vertical scan range
50 Hz - 76 Hz
Vertical scan range
50Hz~146Hz for DVI (dual link) ; DP only
Vertical scan range G2770PF
48Hz~146Hz for DP only
Vertical scan Size(Maximum)
336.15mm
Optimal preset resolution
1920x 1080 @60 Hz
Optimal preset resolution
1920x 1080 @144 Hz for DVI (dual link) ; DP only
Plug & Play
VESA DDC2B/CI
Input Connector
D-Sub 15pin; DVI 24pin; HDMI;DP
Input Connector G2770PF
D-Sub 15pin; DVI 24pin; HDMI/ MHL;DP;
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source
100-240V~, 50/60Hz
Typical power consumption
45W(Test condition: set Contrast = 50, Brightness = 90)
Power Consumption
55W(Test condition: Set Brightness and Contrast to
maximum)
Power consumption
@power-saving
≦0.5W
Off timer
0-24 hrs
Speakers
2WX2
Physical Characteristics
Connector Type
15-pin D-Sub DVI-D HDMI DP
Connector Type G2770PF
15-pin D-Sub DVI-D HDMI/ MHL DP
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25° to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~ 12192m (0~ 40000 ft )
