AOC i2769Vm Service Manual

53
C110,C111,C112,C125,C
126,C145,C310,C320,C3
30,C340
0CH2A-0013A
MLCC ** 10uf，
K,25V,X5R,1.8mm,3216,R/TP
C115,C116,C146,C147,C
150
0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C312,C322,C332,C342,C
345,C346,C348,C353,C3
6,C96,C97,C98,C99
0CH2A-0030A 1uF, K, 10V, X5R, 0.55mm, 1005, R/TP
C136 0CH2A-0049A 1.5nF, 50, -10~+10(K), 1608, X7R(JB)
C95 0CH2A-0068A
10 Volt, X7R(JB), K %, 1005 R/TP, 0.1U F,
T=0.55 MAX
C16,C17,C45,C91 0CH2A-0072A
MLCC ** 10uf，
K,10V,X5R,1.35mm,2012,R/TP
C143 0CH2A-0073A 0.1uF, K, 16V, X7R, 0.55mm, 1005, R/TP
C103 0CH2A-0088A 3.3nF, K, 50V, X7R, 0.9mm, 1608, R/TP
C170,C171,C172,C173,C
174,C180,C181,C182,C1
83,C311,C321,C331,C34
1
0CH2A-0091A 1uF, K, 25V, X5R, 0.6mm, 1005, R/TP
C141,C142 0CH2A-0164A 0.47UF, K, 25V, X5R, 0.95mm, 1608, R/TP
C123 0CH5181K412 180PF, J, 50V, 1608, R/TP, 0.9mm
D3 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0076A SDZ3V3D, AUK, SOD-323, R/TP
D1 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
D8 0DHZL-0110A 1N4448HWS, DIODES, SOD-323, R/TP
D2 0DHZL-0131A SDB0740, AUK, SOT-23, R/TP
D10 0DHZL-0142A SD05, SEMTECH, SOD323, R/TP
F1 0FSLO-0013A F0603HI3000V032T, AEM, Ceramic
US1 0IRTL-0040A
RT6807A, RICHTEK, MNT, VDD BOOST +
VGH BOOST + VGL C/P + VCC BUCK +
L/S + OPAMP + DISCHARGING + GPM +
PVCOM, QFN, R/TP, 48
U1 0ISGL-0008C
M24C04-RDW, STmicroeletronics, 4K, 5ms,
TSSOP, R/TP, 8
UC1 0ITLL-0083A
TL2358EP, TLI, LVDS, 6/8, 2, EPI, 6, 3/4,
DRD, SGIP, AFRC, DGA, SD, SM, SFA,
Z-INV, ESD, LOWELL13, MLF, TR, 48
L1 0LCAA-0039A
DP8L18F-100M, COIL MASTER, 10uH,
M=20%, 1.9A, 114m Ohm, 8.1x6.8x1.8,
R/TP
L2,L3 0LCAA-0089A CMI-DOP3910NH-6R8M, COIL MASTER,
