AOC i2769Vm Service Manual

54
6.8 UH, M=20%, 0.9 A, 0.26 OHM,
3.9X3.9X1 (MM), R/TP
R5,R61 0RH0000B622 0 ohm, 1/16W, 1005, 5%, R/TP
R104,R127,R130,R200,R
203,R205,R221,R222,R2
24,R225,R226,R37,R40,R
45
0RH0000C622 0 OHM 1/10W 0603 0.05R MAX
R135 0RH0221C622 2.2 OHM 1/10W 0603 5%
R30,R31,R32,R33,R34,R
35,R80,R81,R82,R83,R84
,R85
0RH0472C422 47 OHM 1/10W 0603 1%
R2,R3,R6 0RH1000B422 100 ohm, 1/16W, 1005, 1%, R/TP
R146 0RH1000C422 100 OHM 1/10W 0603 1%
R22,R92 0RH1001C422 1K OHM 1/10W 0603 1%
R110,R147,R23,R60,R68,
R70,R71
0RH1002C422 10K OHM 1/10W 0603 1%
R103,R105,R125,R126 0RH1003C422 100K OHM 1/10W 0603 1%
R155 0RH1101C422 1.1K ohm, 1/16W, 1608, 1%, R/TP
R102 0RH1300C422 130 OHM 1/10W 0603 1%
R101,R180,R183 0RH1301C422 1.3K OHM 1/10W 0603 1%
R100 0RH1302C422 13K OHM 1/10W 0603 1%
R141 0RH1601C422 1.6K OHM 1/10W 0603 1%
R151,R185,R188 0RH1602C422 16K OHM 1/10W 0603 1%
R13,R72 0RH2001C422 2K OHM 1/10W 0603 1%
R150 0RH2002C422 20K OHM 1/10W 0603 1%
R122 0RH2200C422 220 OHM 1/10W 0603 1%
R159 0RH2202C422 22K OHM 1/10W 0603 1%
R20,R21 0RH2401C422 2.4K OHM 1/10W 0603 1%
R121 0RH2701C422 2.7K OHM 1/10W 0603 1%
R123,R172 0RH3001C422 3K OHM 1/10W 0603 1%
R10 0RH3300C422 330 ohm, 1/16W, 1608, 1%, R/TP
R142 0RH3900C422 390 OHM 1/10W 0603 1%
R170 0RH3901C422 3.9K OHM 1/10W 0603 1%
R129 0RH3902C422 39K OHM 1/10W 0603 1%
R64 0RH4702C422 47K OHM 1/10W 0603 1%
R90 0RH5101C422 5.1K OHM 1/10W 0603 1%
R186 0RH5102C422 51K OHM 1/10W 0603 1%
R94 0RH5602C422 56K OHM 1/10W 0603 1%
R67 0RH6201C422 6.2K OHM 1/10W 0603 1%
R128 0RH6801C422 6.8K OHM 1/10W 0603 1%
R120,R187 0RH6802C422 68K OHM 1/10W 0603 1%
