3.3 AV/S-Video/Component Video Inputs
3.4 Compatible Mode Table
Dots×Lines
Vertical Horizontal Sync Polarity Presence Screen Mode
Frequency Frequency Horizontal Vertical Horizontal Vertical Normal Full
(Hz) (KHz) (4:3) (16:9)
720×400
70.1 31.5 NEG POS YES YES YES YES
640×480
59.9 31.5 NEG NEG YES YES YES YES
800x600
60 37.9 POS POS YES YES YES YES
1024x768
60 48.363 NEG NEG YES YES YES YES
1360x768
59.79 47.72 NEG POS YES YES YES YES
1400x900 60 55.93 NEG POS YES YES YES YES
1680x1050 60 65.29 NEG POS YES YES YES YES
1920x1080 60 67.50 NEG POS YES YES YES YES
AV (Composite Video Input)
Video1
Video System NTSC/PAL
Amplitude 1.0 Vpp (including sync)
Impedance 75 ohm terminated
S-Video (Y/C Input)
S-Video2
Video System NTSC/PAL
Y signal amplitude 1.0Vpp (including sync)
C signal amplitude 0.286Vpp
Impedance 75 ohm terminated
Component (Y, Pb/Cb, Pr/Cr Input)
Video3
Video system NTSC/PAL
DTV 480i, 480p, 720p, 1080i
Y signal amplitude 1.0Vpp (including sync )
Pr, (R-Y)/Pb, (B-Y) signal
amplitude
0.7Vpp
Impedance 75 ohm terminated
