58
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice.
Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information.
L42H931 E429MANS4WAENN
Location Part No. Description Remark
001G6021 1 SCREW
052G 1185 1 BIG TAPE(Y1200141)
052G 1186 SMALL TAPE
052G 1211 B CONDUCTIVE TAPE 85MM *40MM *0.09MM
052G 2191 A PAPER TAPE
E078 078G0120 2 K SPEAKER 6 OHM 12W 160X42MM
E078 078G0120 2 Y SPEAKER 6 OHM 12W 160X42MM 2nd source
089G 725CAA DB D-SUB CABLE
E08901 089G402A15N IS AC POWER CORD 1500MM AMERICA REG.
092TB1JX1A3WGC BATTERY LR03(EA)2S/G AAA
E09504 095G801312D658 HARNESS 12P(PLUG)-12P(PLUG) 260MM 2nd source
E09504 095G801312X658 HARNESS 12P(PLUG)-12P(PLUG) 260MM
095G8014 4X 54 HARNESS 4P 850/550MM
E09503 095G801410W615 HARNESS 9P-6P+4P 600/700 2nd source
E09503 095G801410X615 HARNESS 10P-6P+4P 600/700
E09501 095G801851D515 LVDS CABLE 51P-30P 400MM 2nd source
E09501 095G801851X515 LVDS CABLE 51P-30P 400MM
E09502 095G8021 3D561 HARNESS 3P-3P 230MM
E09502 095G8021 3W561 HARNESS 3P-3P 230MM 2nd source
098GRABD2NEACR REMOTE CONTROL RC2443801/01
0D1G1730 8120 SCREW
0M1G 930 6120 SCREW
0M1G 930 6120 SCREW
0M1G 930 6120 SCREW
0M1G 940 16 47 CR3 SCREW
0M1G1430 8 47 CR3 SCREW
0M1G1430 8 47 CR3 SCREW
0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649
0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649
0M1G1830 8120 SCREW
0Q1G 930 10 47 CR3 SCREW
0Q1G 930 10 47 CR3 SCREW
0Q1G 930 10 47 CR3 SCREW
0Q1G 940 25 47 CR3 SCREW
0Q1G 940 25 47 CR3 SCREW
705TQ934N09 STAND ASS"Y 42"
0M1G1030 6120 SCREW M3X6
0Q1G 130 8120 SCREW 42A9930011
P15T0437101 BRACKET_BASE_PLATE
P34T0297ADT 1L0120 BASE
P34T0298ADT 1L0100 BASE_SWIVEL
P34T0299ADT 1L0100 BASE COVER
P37T0084011 HINGE_ASSY
Q12G6300 25 3 RUBBER
705TQ934ND4 REAR COVER ASS”Y 42”
P15T0320101 BRACKET_VESA
P34T0296ADT 1A0130 REAR COVER TV42W
P34T0357ADT 1A0100 COVER_REAR_IO
To Next Page
