Item Description
1 BEZEL
2 DECO
6 LENS_IR
7 IR BOARD
8 KEY_FUNCTION
9 KEY BOARD
10 SPEAKER
11 FIX BRACKET
12 PANEL
13 INVERTER BOARD
14 SHIELD_INVERTER
15 BRACKET_VESA
17 RACKET_PCB_SUPPORT
18 BRACKET_BASE
Item Part No. Description Qty
19 BRACKET_SIDE_AV_CN 35 0Q1G 130 8120 SCREW(BASE/BKT) 6
20 SIDE LABEL 36 0M1G6022500 SCREW(BASE/BKT) 4
23 POWER BOARD 37 0M1G1430 8 47 CR3 SCREW(HINGE/BASE_SWIVEL) 1
24 MAIN BOARD 38 0M1G 940 16 47 CR3 SCREW(BASE COVER/REAR COVER) 4
25 BRACKET_VESA 39 0Q1G 940 25 47 CR3 SCREW(BEZEL/REAR COVER) 15
26 REAR COVER 40 0Q1G 930 10 47 CR3 SCREW(FIX BRACKET/PANEL/BEZEL) 1
28 HINGE_ASSY 42 001G6021 1 SCREW(SPEAKER/BEZEL) 2
29 BASE_SWIVEL 43 0Q1G 940 25 47 CR3 SCREW(BRACKET_BASE/PANEL) 4
30 BASE COVER 44 0M1G1740 8120 SCREW(BRACKET_VESA/PANEL) 4
31 BASE 45 0M1G 930 6120 SCREW(INVERTER BOARD/SHIELD_INVERTER/PANEL) 2
32 BRACKET_BASE_PLATE 46 0D1G1730 8120 SCREW(MAIN BOARD/BKT) 4
34 RUBBER 49 0Q1G 930 10 47 CR3 SCREW(MAIN BOARD/BRACKET_SIDE) 2
