32
6. Control Remoto - mal funcionamiento
Control remoto - mal funcionamiento
Reemplace batería
Reemplace el control remot
o
¿Es anormal la IR board?
Si
No
Reemplace IR board
Reemplace main board
No
Si
No
Si
Use otros controles remotos, ¿fun
ciona?
Revise la batería del control remoto
si está
bien colocada o no tiene energía
31
33
Table of Contents
Default Chapter
1
Table of Contents
1
Important Safety Notice
2
Revision List
3
1 General Specification
4
2 Operating Instructions
5
The Front Control Panel
5
Connections
6
Remote Control
7
Instructions for Use
9
3 Input /Output Specification
22
Input Signal Connector
22
Factory Preset Display Modes
23
Mechanical Instructions
24
5 Repair Flow Chart
27
6 PCB Layout
34
Main Board
34
Power Board
38
Inverter Board
41
Key Board
44
IR Board
44
White Balance Adjustment
45
Firmware Instruction
46
DDC Instructions
50
8 Block Diagram
51
9 Schematic Diagram
53
Main Board
53
Power Board
63
Inverter Board
65
Key Board
68
IR Board
69
10 Exploded View
70
Parts List
71
11 BOM List
72
5
Based on 1 rating
Ask a question
Give review
