30
6. Control Remoto - mal funcionamiento
Control remoto - mal funcionamiento
Reemplace batería
Reemplace el control remot
o
¿Es anormal la IR board?
Si
No
Reemplace IR board
Reemplace main board
No
Si
No
Si
Use otros controles remotos, ¿fun
ciona?
Revise la batería del control remoto
si está
bien colocada o no tiene energía
29
31
Table of Contents
Default Chapter
1
Table of Contents
1
Warning
2
Important Safety Notice
2
Revision List
3
1 General Specification
4
2 Operating Instructions
5
The Use of Remote Control
5
To Use the Menus
7
How to Connect
17
Front Panel Control Knobs
19
3 Input/Output Specification
20
RGB Signal Input
20
HDMI Digital Connector Pin Assignments
20
Pin Color Display Signal Cable
20
Compatible Mode Table
21
4 Mechanical Instructions
22
5 Repair Flow Chart
25
6 PCB Layout
32
Main Board
32
Power Board
34
Key Board
37
IR Board
37
ADC Adiustment
38
7 Adjustment
38
FW Upgrade
39
8 Block Diagram
43
Main Board Power System
43
9 Schematic Diagram
44
Main Board
44
AV Input
45
Run as 100 Ohm Differential Pairs
46
Power Board
54
Key Board
56
IR Board
57
10 Exploded View
58
11 BOM List
60
