Item Description

1 DECO

2 BEZEL

3 LENS IR

4 POWER LENS

5 IR BOARD

6 SPEAKER

7 KEY COVER

8 KEY BUTTON

9 KEY BOARD

Item Part No. Description Qty

10 BRACKET 23 001G6021 1 SCREW(SPEAKER/BEZEL) 4

11 BASE HINGE_COVER 24 0Q1G1830 6120 SCREW(IR BOARD/BEZEL) 1

12 BASE STAND_COVER 25 0Q1G 940 14 47 CR3 SCREW(PANEL/BEZEL) 2

13 BASE 26 0M1G1730 6120 SCREW(MAIN BOARD/PANEL/POWER BOARD) 8

14 VESA-BKT-TOP 27 0Q1G 330 8 47 CR3 SCREW(MAIN BOARD/SIDE BKT) 1

15 BRACKET PANEL_SUPPORT_TOP_L 28 0M1G 330 6 47 CR3 SCREW(MAIN BOARD/SIDE BKT) 1

16 BRACKET PANEL_SUPPORT_TOP_R 29 0M1G1740 6120

SCREW(BKT/PANEL/VESA/HINGE BKT）

17 REAR COVER 30 0M1G 330 6 47 CR3 SCREW(MAIN BOARD/BTM BKT) 1

18 PANEL 31 0M1G1740 14 47 CR3 SCREW(HINGE BKT/HINGE COVER) 2

19 POWER BOARD 32 0Q1G 940 25 47 CR3 SCREW(STAND/HINGE COVER) 4

20 MAIN BOARD 33 0Q1G 940 25 47 CR3 SCREW(BASE/STAND) 4

21 BKT-PCB-RA-SIDE 34 0M1G 940 8 47 CR3 SCREW(REAR COVER/VESA/BKT/HINGE BKT) 6

22 BKT-PCB-MAIN-BOT 35 0Q1G 940 16 47 CR3 SCREW(REAR COVER/BEZEL) 10
