63
R9 061G04021302FI RST CHIP 13K 1/16W 1% TA-I
R5 061G04021801FI RST 0402 1.8K 1% 1/16W TA-I
R7 061G04022701FI TEST ONLY RST CHIP 2.7K 1/16W 1% TA-I
R1 061G04024701FI RST 0402 4.7K 1/16W 1% TA-I
R8 061G04025601FI TEST ONLY RST 0402 5.6K 1% 1/16W TA-I
R2 061G04027500FT RST 0402 750R 1% 1/16W
R3 061G04028200FI RST 0402 820R 1% 1/16W
SW7 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
SW5 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
SW3 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
SW01 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
SW6 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
SW4 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
SW2 077G 607 2 FD
CHIP TACT SW BY FORWARD
SFKQGMA2125T-PL
E715 715G5795K01000004S KEY BOARD PCB
M03602 Q36G 600 18111 TS NON-WOVEN FABRIC CLOTH 0.25 0.3
Q52G1501150523AWYY TAPE_INSULATING
0Q1G 930 10 47 CR3 SCREW M3X10
0Q1G 930 10 47 CR3 SCREW M3X10
M01101 Q11G701017000L00XL PCB-SUPPORT
M03602 Q36G 600 18111 ZA NON-WOVEN FABRIC CLOTH 0.25 0.3
M03601 Q36G 600 35 3 ZA NON-WOVEN FABRIC CLOTH 0.3 0.3
M04502 Q45G88010TV05200X1 PE PACKING
E750 LCM185BGE02A031X0F PANEL TPM185B1-BGEL02 C1D FQ TPV 2nd Source
LE22D1331/30 E2AC11NSAPE8NN
Location Part No. Description Remark
092GB1JX1A3EGC BATTERY 1.5V LR03 AAA ALKALI
E750 750GBV215T01C6N000 LCD TPM215HW01-DAT01 R00C WH TPV
756TXCCB01S004006Q MAIN BOARD-CBPFW3QSA3Q
SMTF-U402 100TAMVI003S6X MCU ASSY-356G2233073
U402 356G2233073 FLASH W25Q64FVSSIG 64MB SOIC8 2.7~3.6V
Q44GCA1461502C00HX ARTWORK CARTON LE22D1331
X15T860420200000BL BKT_BTM
X15T861320100000BL BKT_POWER_TOP
X34T00860GM03K0330 REAR_COVER
X34T0087ADTZ1L01SP BEZEL
E08901 089G202A15N IS AC POWER CORD 1500MM
0M1G1030 6120 SCREW 3X6
0M1G1030 8120 SCREW
M00104 0M1G1740 16 47 BGP SCREW
M00104 0M1G1740 16 47 CR3 SCREW
M00101 0Q1G 930 10 47 H1 SCREW
M00101 0Q1G 930 10 47 RA SCREW
M00102 0Q1G 930 12 47 RA SCREW
M00102 0Q1G 930 12 47 XL SCREW
SP01 378G0035566YAH 16 OHM 3.5W L100XW27 100 NO
ECN601 395G801304LN05 HARNESS 4P-2P+2P 290/260
ECN701 395G801313XM73 HARNESS 13P-13P 100
