AOC LE19D1331/30 User Manual

73
NR9902 061G 58159LAW 5A NTCR 1.5R 15% 2.4W SCK101R55LMY502
R9130 061G153M47159B SY RST MOF 470R 5% 3W
C9901 063G107M474AUM CAP X2 470NF 20% 305V
FB9908 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A)
FB9902 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A)
L9901 073G 174192 X LINE FILTER 30MH MIN ET20 0.8A
L9102 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9101 073G 253 91 V CHOKE COIL 3.5UH+-10%
L8102 073G 253214 X CHOKE COIL 47UH 10% ,HF
T9101 080GL32P 92 YS X'FMR 800UH 10% 20UH EFD30 YS04160400
CN9901 087G 50147C DL AC SOCKET V/T 2P ACT1MD-02BL4B006 H=14
BD9101 093G 50460 50 BRIDGE GBL08 4A/800V GBL
D8101 093G 60924 DIODE SR510-22 DO-201AD
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
CN8101 311GW200A06ABX WAFER 2.0MM 6P
CN9101 311GW250B13BBX WAFER 2.5MM 13P R/A 35MM 7MM
C9101 367G215X470PKZ002S EC 47UF 20% 450V 12.5*36 2000 HR 420MA P
C9102 367G215X470PKZ002S EC 47UF 20% 450V 12.5*36 2000 HR 420MA P
BD9101 393G0050460A03 BRIDGE GBL408-C 4A 800V GBL 150A
705TXC5799500Q Q9101 ASS'Y
Q9101 057G 667931 MOSFET AOTF8N65 8A 650V TO-220FP
0M1G1730 8120 SCREW 3X8
Q9101 357G0667A11 MOSFET STF6N65K3 5.4A 650V 30W TO-220FP
HS3 Q90G0219 4 HEAT SINK ÐͲÄ/PROFILE
705TXC8402300Q F9901 ASS'Y
F9901_1 084G 34 14 FUSE -- -- --
F9901 084G 41 3 C FUSE 3.15A 250V UDA3.15(PF)
705TXC9399500Q D9101/D9102 ASS'Y
D9101 093G 60931 DIODE MBRF1560CT ITO-220AB
D9102 093G 60946 SCHOTTKY MBRF20150CT C0 20 150 ITO-220AB
0M1G1730 8120 SCREW 3X8
HS1 Q90G0219 5 HEAT SINK ÐͲÄ/PROFILE
IC9101 056G 379190 AC/DC CONVERTER LD7750RGR SOP-7
IC8501 056G 700 34 LED DRIVER PF7001S SOP-14
Q9103 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q9102 057G 419913 T TRANSISTOR 2SD1623S-TD-E PCP
Q8101 057G 763958 MOSFET AO4482L 6A 100V SO8
R9128 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA
R9131 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA
R9121 061G0805102 JI RST 0805 1K 5% 1/8W
R9124 061G0805102 JT RST CHIPR 1K OHM +- 5% 1/8W TZAI YUAN
R8106 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA
R9111 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA
R9114 061G0805104 JT RST CHIPR 100KOHM +- 5% 1/8W TZAI YUAN
R8121 061G08051309FI RST 0805 13R 1% 1/8W
R8122 061G08051309FI RST 0805 13R 1% 1/8W
R8123 061G08051309FI RST 0805 13R 1% 1/8W
R8125 061G08051309FI RST 0805 13R 1% 1/8W
R8124 061G08051309FI RST 0805 13R 1% 1/8W
R8105 061G0805150 JT RST CHIP 15R 1/8W 5% TZAI YUAN
R8119 061G0805154 JT RST CHIP 150K 1/8W 5% TZAI YUAN
R8111 061G0805183 JT RST CHIP 18K 1/8W 5%
R8102 061G08052003FT RST CHIP 200K 1/8W 1%
R8108 061G0805201 JT RST CHIPR 200OHM +-5% 1/8W TZAI YUAN
R9126 061G08052431FY RST CHIP 2K43 1/8W 1%
R8104 061G0805330 JI RST CHIPR 33 OHM +-5% 1/8W 0805
R9123 061G08053301FY RST CHIP 3K3 1/8W 1%
