AOC LE24A1330 User Manual

36
8.3 IR Board 715G5671R01000004X
R204
100R 1/10W 5% R0603
R201
15K 1/16W
R0402
IR
033G8032 5F HR
VCC
081G 14 24 EL
OEM MODEL
Size Rev
Date
Sheet
of
TPV MODEL
PCB NAME
〠⡩
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
㎜䳄⬌㎚㞩
A
A
22Friday , June 22, 2012
〠⡩
<>
02-IR&LED
R203 220 OHM 1/10W
LED_B
CN201
CONN
1 2 3 4 5
67
LED_R
RED
BLUE
LED201 LED
1 23
4
R202 220 OHM 1/10W
U201
IRM-H938M3/TR2
GND
1
GND
2
OUT
3
VCC
4
change flat type emitting terminal_120405 by Mars
SMD LED
Top View
SMD IR
10 mm
42.55mm
VCC
C201 2.2UF 16V
