66
LE24H067
Item Description
1 PANEL
2 MAIN BOARD
3 POWER BOARD
4 HINGE BKT
5 SIDE IO BKT-USA
6 BEZEL
7 SPEAKER
8 IR BOARD
9 REAR COVER
10 AC COVER
11 AC BKT
12 BKT-VESA
13 KEY
14 KEY COVER
Item Part No. Description Qty
15 KEY BOARD 19 0M1G1740 12225 CR3 SCREW(HINGE/STAND/COVER/HINGE BKT) 7
16 HINGE 20 0Q1G 940 8 47 CR3 SCREW(BEZEL/REAR COVER) 2
17 STAND 21 0M1G 940 8 47 CR3 SCREW(AC/AC BKT/REAR COVER/PANEL) 3
18 BASE 22 0M1G 930 6 47 CR3 SCREW(REAR COVER/HDMI) 1
28 FOOT PAD 23 0Q1G 930 8 47 CR3 SCREW(REAR COVER/AV) 1
29 DECO 24 0M1G1730 8120 SCREW(POWER BOARD/MAIN BOARD) 9
30 CHIP LED WHITE 25 0M1G1730 6120 SCREW(AC BKT/PANEL) 2
31 LED BOARD 26 0M1G1740 6120 SCREW(PANEL/HINGE BKT) 3
32 DECO_BEZEL 27 0Q1G 940 8 47 CR3 SCREW(HINGE BKT/REAR COVER) 2
