AOC LE24H067 Service Manual

68
CN903 033G8029 3A H B2P3S-VH
040G 45762412B CBPC LABEL
IC902 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4
IC902 056G 139 10 IC TLP781F PHOTOCOUPLER DIP-4
NR901 061G 58509MEW NTCR 5R 5A SCK13055MMY506
C915 063G107M47410M CAP X2 0.47UF 20% 275VAC
C919 065G306K4712B3 Y1 CAP 470PF +-10% 250VAC CD SERIES
C925 065G306M6812B3 Y1 CAP 680PF +-20% 250VAC CD SERIES
C927 065G306M6812B3 Y1 CAP 680PF +-20% 250VAC CD SERIES
C932 067G 4151218KV EC 120UF 20% 63V EP 12.5*12
C944 067G 4151218KV EC 120UF 20% 63V EP 12.5*12
C911 067G204V471 2K CS CAP 470UF 10V 8*8 MM
C905 067G204V680 4K CAP CS 68UF 20% 25V 8*11
C926 067G204V680 4K CAP CS 68UF 20% 25V 8*11
C917 067G215C4706KV EC 47UF 20% 35V EM 8*9
C912 067G215C4713KV LOW ESR EC 470UF 16V 8*9MM
C902 067G305L10122K EC 100UF 20% 220V PZ 10*45
C903 067G305L10122K EC 100UF 20% 220V PZ 10*45
FB903 071G 55 21 FERRITE BEAD
FB902 071G 55 21 FERRITE BEAD
L903 073G 174157 H1 LINE FILTER 19MH MIN LCL-11618 HA
L902 073G 253 91 L CHOKE BY LI TA
L901 073G 253 91 L CHOKE BY LI TA
L904 073G 253208 L CHOKE COIL 100UH 5% CC-012850-1
T901 080GL32P 12 S X'FMR 700UH 15% BCK-P33-26609
BD901 093G 50460511 BRIDGE KBP208GL 4A/800V
BD901 093G 50460922 BRIDGE DIODE UR4KB80 D3K
705TQ957072 Q901 ASS'Y
Q901 057G 667 51 FET 2SK4101LS 7A/650V TO-220FI(LS)
Q901 057G 667931 TEST ONLY
0M1G1730 8120 SCREW
HS901 Q90T0195 1 HEAT SINK
705TQ993101 D901/D908 ASS"Y
D901 093G 60239 FME-210B T0-220
D908 093G 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS)
D901 093G 60903 DIODE MBRF10150CT TSC
D908 093G1506 2 FMW-2156
0M1G1730 8120 SCREW
Q90T0194 1 HEAT SINK
IC901 056G 379529 IC LD7576AGR SOP-7
IC904 056G 700 2 IC RT8482GS SOP-16
Q920 057G 763945 MOSFET AO4438 SO-8
Q920 057G 763950 MOSFET FDS5690 SO-8
R936 061G0805101 JT RST CHIP 100R 1/8W 5% TZAI YUAN
R936 061G0805101 JY RST CHIPR 100OHM +- 5% 1/8W YEGAO
R940 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA
R940 061G0805102 JT RST CHIPR 1K OHM +- 5% 1/8W TZAI YUAN
R915 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA
R937 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA
R932 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA
R932 061G0805103 JT RST CHIPR 10K OHM +- 5% 1/8W TZAI YUAN
R915 061G0805103 JY RST CHIPR 10KOHM +-5% 1/8W YAGEO
R937 061G0805103 JY RST CHIPR 10KOHM +-5% 1/8W YAGEO
R949 061G08051202FT RST CHIP 12K 1/8W 1%
