AOC LE24H067 Service Manual

87
ZD109 093G 64 37 N VPORT0603100KV05
ZD108 093G 64 37 N VPORT0603100KV05
ZD107 093G 64 37 N VPORT0603100KV05
ZD106 093G 64 37 N VPORT0603100KV05
ZD105 093G 64 37 N VPORT0603100KV05
ZD104 093G 64 37 N VPORT0603100KV05
ZD103 093G 64 37 N VPORT0603100KV05
D605 093G 6432P LL4148
D602 093G 6432P LL4148
D103 093G 6432P LL4148
D102 093G 6432P LL4148
D101 093G 6432P LL4148
ZD701 093G 39S155 BZT52-C5V6
D604 093G 60S 15 T DIODE RB160M-60TE25 SOD-123 ROHM
D704 093G3004 3 SM340A
E715 715G3759M01000005F MAIN BOARD PCB 2nd source
E715 715G3759M01000005K MAIN BOARD PCB
P90T0051201 HEAT SINK --
IRPFAQE8 IR BOARD
U201 056G 627 14 1M IC KSM-2003TN2M-S 37.9KHZ
CN201 033G8032 3F HR CONNECTOR 3P 1.25
R201 061G0603153 JY RST CHIPR MAX 15KOHM 1/10W YAGEO
C201 065G060310432K A CAP CHIP 0603 100NF K 50V X7R
E715 715G4086R01000004L IR BOARD PCB 2nd source
E715 715G4086R01000004S IR BOARD PCB
E750 LCM215H1L01A33L PANEL TPM215HW01-H1L01 C1D FQ TPV
Q02T7039 1 STAND OFF
Q15T0754101 HINGE BKT
Q40G 22061544A RATING LABEL
Q40G000367314A LABEL --POP FOR LE22H067&LE24H067 USA&CA
Q41G24MV615 1C MANUAL
Q41G78SV61518A QUICK SETUP GUIDE --
Q44GC140101 EPS
Q44GC140201 EPS
Q44GC140615 3A CARTON --
Q45G 77 5 PE PACKING (Y1900241)
Q45G 99626 35 PE BAG
Q45T 99609100 EPE COVER
Q50G 4 10 TIE (Y1900221)
Q50T 500523 CABLE TIE
Q52G 1150523 TAPE_INSULATING
Q52G 1211824 AL TAPE
Q52G6025 15273 MYLAR
Q85G 583195 GASKET
Q85G 583200 6 EMI PAD
M037 SA37T0162021 HINGE ASS'Y
015F016201L BRACKET
015F016203R BRACKET
015F0162020 BRACKET
028F0618070 SHAFTS
002F0604100 00 NUTS
004F061210T 01 METAL WASHERS12.0*4.72*1.0T
004F061212T 00 WASHER
004F061210M 00 METAL WASHERS12.0*6.03*4.70H
