AOC LE24H067 Service Manual

89
LE24H067 E2CA6ZNKWEE6NN
Location Part No. Description Remark
050G 600 2 HANDLE1
050G 600 3 HANDLE2
052G 1185 MIDDLE TAPE (Y1200141)
052G 1185 1 BIG TAPE(Y1200141)
052G 1186 SMALL TAPE
052G 1211 A CONDUCTIVE TAPE 55MM *45MM *0.08MM
052G 1211537 CONDUCTIVE TAPE 100MM*60MM*0.08MM
052G 1211543 ALUMINUM FOIL TAPE
052G 2191 A PAPER TAPE
E08901 089G402A18NHL4 A1 AC POWER CORD --1800
E08901 089G402A18NLT4 A1 AC POWER CORD 1800MM 2nd source
ECN701 095G801313D913 HARNESS 13P-12P 120MM FQE92067I
ECN701 095G801313X913 HARNESS 13P-12P 120MM LCDXXTF0433 2nd source
ECN408 095G801832D903 HARNESS 30P-32P 140MM FQE92071I
ECN408 095G801832X903 HARNESS 30P-32P 140MM LVDSXTF0185 2nd source
098GR7BDBNEACD REMOTE CONTROL 90-364100T4401
0M1G 930 6 47 CR3 SCREW
0M1G 930 6 47 CR3 SCREW
0M1G 940 8 47 CR3 SCREW
0M1G1140 6120 SCREW
0M1G1730 4120 SCREW
0M1G1730 6120 SCREW,42-D020523
0M1G1730 8120 SCREW
0M1G1740 6120 SCREW
0M1G1740 12225 CR3 SCREW
0Q1G 930 8 47 CR3 SCREW
0Q1G 940 8 47 CR3 SCREW
0Q1G 940 8 47 CR3 SCREW
705TQ949001 COMSUPTIVE ASS'Y-A4
705TQA34K18 BEZEL ASS`Y
036T 600 18109 NONWOVEN FABRTC
0Q1G1030 6120 SCREW
A33T0908ADT 1L0100 KEY
A33T0909ADTB1L0100 KEY COVER
A34T1845AFLB1L0130 BEZEL TV23.6
A34T1846AHY 1C0100 DECO
Q35T0075BBV 1L0100 DECO_BEZEL_TV 23.6"
Q35T0077 1A1C0100 DECO BACK LIGHT
Q36T 600 35 2 GP NONWOVEN FABRIC
705TQA34K19 REAR COVER A`SSY
A34T1832ADT 4A0130 REAR COVER_TV236WSL-10B3
P15G8299 1 BKT-VESA
705TQA34K20 STAND ASS`Y
0M1G1740 12 47 CR3 SCREW
A34T1848AFL 1L0133 BASE_TV236WSL-AOC1
A37T0162031 HINGE
Q12G6082 3 FOOT PAD
Q34T7147AFL 1L0100 STAND
756TQACB ZK035 02 MAIN BOARD-CBPFAZ9KQ4
U105 056G1133918 IC AT24C02BN-SH-T 8-SOIC
U405 056G1133939 IC MX25L3205DM2I-12G SOP-8
