AOC LE24H067 Service Manual

95
U606 056G 616916 IC MAX9728AETC+ TQFN-EP-12
U404 056G 643 41 IC APX809-29SAG-7 SOT23
U410 056G 662 13 IC AZC099-04S SOT23-6L
U408 056G 662 22 IC AZC199-02S.R7G SOT23-3L
U108 056G 662502 C ESD AZC199-04S SOT23-6L
U109 056G 662502 C ESD AZC199-04S SOT23-6L
U504 056G 662502 C ESD AZC199-04S SOT23-6L
U507 056G 662502 C ESD AZC199-04S SOT23-6L
U406 056G1133 83 1 IC M24C64-WMN6P 64K SO-8 ST
U406 056G1133153 IC EEPROM CAT24C64WI-GT3 SOP8 64KB
U105 056G1133918 IC AT24C02BN-SH-T 8-SOIC
U405 056G1133939 IC MX25L3205DM2I-12G SOP-8
U103 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23
U104 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23
U106 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23
U107 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23
Q101 057G 417511 MMBT3904
Q102 057G 417511 MMBT3904
Q103 057G 417511 MMBT3904
Q104 057G 417511 MMBT3904
Q105 057G 417511 MMBT3904
Q106 057G 417511 MMBT3904
Q404 057G 417511 MMBT3904
Q601 057G 417511 MMBT3904
Q603 057G 417511 MMBT3904
Q605 057G 417511 MMBT3904
Q704 057G 417511 MMBT3904
Q708 057G 417511 MMBT3904
Q501 057G 759 2A TANSISTOR 2N7002 SOT-23
Q505 057G 759 2A TANSISTOR 2N7002 SOT-23
Q504 057G 759 2A TANSISTOR 2N7002 SOT-23
Q503 057G 759 2A TANSISTOR 2N7002 SOT-23
Q502 057G 759 2A TANSISTOR 2N7002 SOT-23
Q403 057G 763 79 FET AO4449 -7A/-30V SOIC-8
Q703 057G 763 79 FET AO4449 -7A/-30V SOIC-8
Q705 057G 763 79 FET AO4449 -7A/-30V SOIC-8
R432 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R431 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R430 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R429 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R428 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R107 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R103 061G0402470 JF RST CHIPR 47 OHM 5% 1/16W FENGHUA
R432 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R431 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R430 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R429 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R428 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R107 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R103 061G0402470 JY RST CHIPR 47 OHM 5% 1/16W YAGEO
R486 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R493 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R4A7 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R4B3 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

AOC LE24H067 Specifications

General

Brand	AOC
Model	LE24H067
Category	LCD TV
Language	English
