3.3 Compatible Mode Table
LE32W157
Analog RGB:
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq. (Hz)
Sync
Polarity
Nominal
Pixel Clock
(MHz)
VGA
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
640x480@75Hz 840 x 500 37.5 N 75 N 31.500
720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
SVGA
800x600@56Hz 1024 x 625 35.156 P 56.25 P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
800x600@72Hz 1040 x 666 48.097 P 72.188 P 40.000
800x600@75Hz 1056 x 625 46.875 P 75 P 49.5
XGA
1024x768@60 Hz 1344x806 48.363 N 60.004 N 65.000
1024x768@70 Hz 1328x806 56.476 N 70.069 N 75.000
1024x768@75 Hz 1312x800 60.023 P 75.029 P 78.750
WXGA 1360x768@60 Hz 1792X795 47.712 P 60.015 P 85.5
HDMI
Nominal Nominal Nominal
Mode Resolution Total
Horizontal
Frequency(KHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
1080P 1920X1080 67.5 60 148.50
720P 1280×720 1650 x 750 45.00 60 74.25
1080i 1920X1080 2200 x 1125 33.75 60 74.25
480P 720X480 858 x 525 31.50 60 27.03
480i 720X480 1716 x 525 15.75 60 13.51
Component
Industry
Code
Input signal
Format
Display performance description
Interlace
rate
Partition
Total
Line Per
Frame
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Sampling
Frequency
(MHz)
Aspect
720P
1280×720P*
1:1 750 45 60 74.25 16:9
1080i
1920×1080i*
2:1 1125 33.75 60 74.25 16:9
480i 720x480i 2:1 525 15.75 60 13.51
480P 720x483P 1:1 525 31.47 60 27.00
