22
Compatible Mode Table
RGB Input Signal Timing
Dots × Lines
Vertical Horizontal Sync Polarity Presence Screen Mode
Frequency Frequency Horizonta
Vertical Horizonta
Vertica
FULL
(Hz) (KHz) (16:9)
640 X 480
59.9 31.5 NEG NEG YES YES YES
720 X 400
69.6 31.3 NEG POS YES YES YES
800 X 600
60 37.9 POS POS YES YES YES
1024 x 768
60 48.3 NEG NEG YES YES YES
1360 X 768
60 47.7 POS POS YES YES YES
1920 X 1080
60 67.4 POS POS YES YES YES
